Technical Specifications:

• Compliance: 2006/42CE certification and guarantee of optimal safety thanks to Veritas certification.
• Size:
  • Height: 1400 mm
  • Ground Grip:
    • Length: 650 mm
    • Width: 400 mm
• Operating pressure: 6 bar (max: 8 bar).
• Compressive force: 1226 kg.
• Weight: 62 kg.

Built-in Equipment:

• OP2003: Articulated upper jaw for automatic adaptation to springs.
• OP2009: Cup Ø105 to Ø182 mm, suitable for vehicles such as Mégane, C3, Stylo, etc.
• SA6916: Cup Ø78 to Ø130 mm for extended coverage of vehicle models.
• SA6906: Fall protection support for enhanced safety.
• SA2035: Integrated air supply break, guaranteeing an automatic cut-off when the safety grille is opened (OP2005).

Benefits:

• Innovative system:
  • Articulated jaws for automatic adjustment during compression, allowing the springs to be held firmly, even with spaced turns.
• Maximum Security:
  • Protective grille with automatic air break to guarantee the safety of the operator.
• Reliability and Versatility:
  • Ideal for garages and mechanical professionals, covering a wide range of vehicles.

Applications:

Designed for intensive use in mechanical workshops, this compressor is perfectly matched to the springs of light vehicles, guaranteeing fast, precise and safe work.

Order the Veritas Certified Air Spring Compressor now on Zoneautopro to equip your workshop with a high-performance, safe tool that complies with European standards.
