Technical Specifications

Specification	Detail
Power supply	230V AC 50/60 Hz
Dimensions (H min/max)	87 x 50 x 98-139 mm
Weight	0.420 kg
Maximum pressure	16 bar
Connection	1/2'' Inlet - 1/4'' Outlet
Power	15 VA
Time adjustment closure	0.6 to 49 minutes
Opening adjustment time	1 to 15 seconds

---

Advanced Features

• Automatic Condensate Removal: Adjustable to fit the reserve to be purged, ensuring optimal operation.

• LED indicators:

  • LED ON : Indicates power on.
  • LED Drain : Indicates that the valve is open.
  • Test button : Allows you to manually check that it is working properly.

• Setting Options:

  • Closing Time : Adjustable to set the interval between each purge.
  • Opening Time : Adjustable to control the duration of each purge.

• Connectivity & Accessories:

  • DIN connector with cable.
  • Built-in shut-off valve.
  • Filter to ensure system cleanliness.

---

Easy Installation

1. Connection:

   • 1 /2'' M inlet and 1 /4'' F outlet.
   • Plug in the power supply after checking the voltage.

2. Settings:

   • Adjust the opening and closing times according to your needs (MIN and SEC).
   • Open the faucet in an upright position.

3. Test:

   • Press the test button to verify the installation.

---

Simplified maintenance

• Close the valve in the horizontal position.
• Clean the filter to prevent the build-up of impurities.
• Perform periodic maintenance of the solenoid valve to ensure optimal operation.

---

Benefits

• Reliability: Automated and accurate purge management.
• Adaptability: Customized settings to meet specific needs.
• Durability: Robust design with resistant seals.
• Efficiency: Reduced air loss and improved overall performance.

---

Applications

• Tire Industries: To evacuate condensate into compressed air networks.
• Workshops and Factories: Ideal for compressors and pneumatic systems.
• Preventive maintenance: Extends equipment life and reduces breakdowns.

---
