🔧 Technical characteristics

• Lifting capacity : 3 tons (3000 kg)

• Maximum lifting height : 1200 mm

• Minimum height : 135 mm

• Emergence time : 45 seconds

• Lifting system : Double hydraulic cylinder for stable and vibration-free climbing

• Security :

  • Mechanical rack and pinion lock with manual release

  • Hydraulic parachute to prevent overloading

• Power supply :

  • 2.2 kW motor

  • Operates on 220 V

  • Mobile control box powered by 24 V to avoid the risk of electric shock

• Total weight : 450 kg

• Recommended workspace dimensions : 4 x 6 meters

• Minimum thickness of the concrete slab : 15 cm

✅ Benefits and features

• Mobility : Equipped with sturdy wheels, the deck is easily movable and can be folded up for easy storage

• Versatility : Swivel and extendable lifting arms, suitable for the majority of light vehicles

• Enhanced safety : Mechanical and hydraulic systems in accordance with European standards

• Compact design : Ideal for workshops with limited space

• Robustness : Reinforced steel frame, designed for intensive use
