Key features

• Wireless CCD heads:

  • 4 heads equipped with 8 sensors for increased accuracy.
  • Wireless communication with industrial 2.4 GHz radio technology.
  • System always calibrated and ready to use thanks to an integrated charging base.

• EXACT PLUS Professional Software:

  • Clear, intuitive and customizable graphics.
  • More than 18,000 car and van models in the database.
  • Option for HGVs and buses with a database of more than 3,000 vehicles.
  • Quick procedures such as "Easy Caster" for measuring caster and "Quick Check" for quick front axle check.

• Push OCR Technology:

  • Allows for precise control by simply pushing the vehicle.

• Wide Compatibility:

  • Works with Asa Network, RH-Meter, and Romess CM-09606.

---

Technical specifications

• Measurement Ranges:

  • Total parallelism: ±48°
  • Semi-parallelism: ±24°
  • Camber: ±10°
  • Flush: ±30°
  • Pivot angle: ±30°
  • Wheel Offset: ±22°
  • Thrust angle: ±22°
  • Steering angle: ±22°

• Feeding:

  • CPU: 90-260 VAC (50-60 Hz), 1 phase.
  • Consumption: 0.4 kW.

• Size:

  • Heads: 800 x 135 x 210 mm.
  • Operator station: 800 x 630 x 1710 mm.
  • Total system: 1350 x 1320 x 1710 mm.

---

Available Models

1. Exact 70 Radio (VL):

   • Furniture on wheels.
   • Wireless lifters.
   • PC with Windows XP Embedded.
   • EXACT PLUS software.
   • Pedal press and steering wheel lock.

2. Exact 70 Radio Truck Professional (PL):

   • Contents of the VL model.
   • Self-centering calipers for trucks and trailers (17.5" to 25").
   • Activation card for truck database.

---

Key Benefits

• Speed and Simplicity: System without bridge or stem, easy and intuitive unveiling of the wheels.
• Permanent precision: Automatic calibration of CCD heads without manual intervention.
• Versatility: Suitable for light vehicles, HGVs, trailers and buses with dedicated options.
• Maximum Efficiency: Designed for daily use in a professional workshop.
• Scalability: Compatible with vehicle databases for continuous updating.

---

Commissioning and Training

• Equipment installation: 2 hours.
• Usage training: 3 hours.
• Travel included.

---

Applications

• Precise alignment control of light vehicles, trucks and trailers.
• Professional garages, technical inspection centres and specialised workshops.

---

Order your Corghi Exact 70 Radio PL Alignment Controller today on ZoneAutoPro.com and benefit from a state-of-the-art solution for your automotive geometry needs!
