Approved Brands

• Fiat
• Alfa Romeo
• Lancia
• Fiat Pro
• Abarth
• Jeep

---

Technical specifications

1. Measurement Ranges:

   • Total parallelism: ±20°
   • Semi-parallelism: ±10°
   • Camber: ±10°
   • Flush: ±30°
   • Pivot angle: ±30°
   • Wheel Offset: ±10°
   • Thrust angle: ±8°

2. Feeding:

   • CPU: 90-260 VAC (50-60 Hz), 1 phase.
   • Consumption: 0.4 kW.

3. Size:

   • Heads: 840 x 115 x 280 mm.
   • Operator station: 800 x 630 x 1710 mm.
   • Total system: 1350 x 1320 x 1710 mm.

---

Features of Wireless Heads

• Lightweight Design: Each head weighs only 3.2 kg, with an oversized arm suitable for large wheels.
• Advanced Technology:
  • 2 high-resolution cameras per head.
  • Electronic inclinometer and spirit level.
  • Low light sensitivity for working in all conditions.
• Easy charging: Rechargeable AA batteries with charging port built into the cabinet.
• Automatic calibration: Continuous calibration control for guaranteed accuracy.

---

EXACT PLUS Software

• Extensive Database: More than 20,000 vehicles referenced.
• Intuitive interface:
  • Animated cursors and color coding for easy remote work.
  • Graphic printouts and animations help with adjustment.
• Advanced features:
  • Live measurement and adjustment of the incidence and tilt of the knuckle pivot (KPI).
  • Compatibility with Cal one-Touch®, Aligner Online, and Asa Network systems.
  • ROMESS CM-09606 inclinometer holder.

---

Accessories & Options

• Swivel trays not included: These trays must be ordered separately.
• Optional Support: Animations and adjustment aids.

---

Benefits

1. Maximum Accuracy: Precise measurements with 8 high-tech sensors.
2. Ease of use: Wireless system, automatically calibrated and ready to use.
3. Speed: Unveiling of the wheels and simplified control thanks to advanced technology.
4. Wide Compatibility: Suitable for a wide range of vehicles, approved by major manufacturers.
5. Professional Quality: Designed for daily use in the workshop.

---

Applications

• Automotive repair shops.
• Technical inspection centres.
• Demanding professionals in search of precision and efficiency.

---

Order your Corghi Exact 7 Alignment Controller today on ZoneAutoPro.com and discover an innovative and high-performance solution for your alignment checks!
