Technical Specifications:

• Main lifting capacity: 16 tons.
• Auxiliary lifting capacity: 6 tons (optional).
• Lifting height:
  • Minimum: 240 mm.
  • Maximum: 1,540 mm.
• Platform dimensions:
  • Length: 8,000 mm.
  • Width: 810 mm.
• Distance between platforms: 1,000 mm.
• Width between columns: 3,500 mm.
• Total width: 9,580 mm.
• Lifting time (rise): 90 seconds.
• Engine power: 5.5 kW.
• Standards: Complies with E.C. requirements

Strengths:

1. Perfect Timing Technology:

   • The motors are connected by bevel drive shafts and gearboxes in an oil bath, ensuring a perfectly level climb and uniform load distribution.

2. Reduced maintenance:

   • No adjustments required after initial installation.
   • No cables or carrier chains that can stretch or flex.

3. Optimal security:

   • Heavy-duty safety catches.
   • Up and down limit switches to prevent overtaking.
   • Safety micro-switch activated in case of failure or obstacle during descent.

4. Automatic Lubrication:

   • Equipped with a piston pump in each column to lubricate nuts and pins, ensuring increased longevity and smooth operation.

5. Robust Design:

   • Wide and long platforms to accommodate large vehicles.
   • Motors protected by thermal relays against overloads or electrical failures.

6. European Compliance:

   • Designed and manufactured to strict E.C. standards, providing reliability and safety.

Applications:

• Heavy truck maintenance: Perfect for trucks, buses, and other heavy-duty commercial vehicles.
• General repairs: Ideal for the control of running gear, engines, and braking systems.
• Technical Centers: Essential tool for periodic inspections and in-depth diagnostics.

Why Choose this 16T PL Lift?

• Powerful Ability: Lifts up to 16 tons for a variety of applications.
• Secure Design: Multiple protection devices for safe use.
• Simplified maintenance: Initial adjustments and automatic lubrication for hassle-free operation.
• Versatility: Long platforms suitable for large vehicles.
• European sustainability: High-quality materials and design for intensive use.

Order today on ZoneAutoPro.com to equip your workshop with a reliable, safe and efficient 16T PL 4-post lift . For any assistance or request for additional information, our team is at your service to assist you in your choice!
